High-Performance, Polymer-Modified, Fibre-Reinforced Repair Mortar
hahne RepoStruct 40 is a one-component, pre-batched, polymer modified, shrinkage-compensated, fibre-reinforced repair mortar. Designed for both pourable and spray applications, it offers superior mechanical strength, low permeability, and excellent bond with old concrete. It is ideal for structural and large-volume repairs requiring thicknesses of 10 mm to 50 mm in vertical or overhead sections.
- High compressive strength with early strength gain
- Low rebound and excellent pumpability
- Shrinkage controlled for crack-free repairs
- Excellent bond to concrete and reinforcement
- Chloride-free and non-corrosive
- Compatible with HAHNE protective coatings and waterproofing systems
- Restoration of damaged or spalled structural concrete
- Jacketing and rebuilding of columns, beams, and walls
- Repair of fire-damaged and chloride-affected concrete
- Large-area reinstatement of industrial and marine structures
- Micro-concrete infill behind shuttering where vibration is difficult
| Property | Test Method | Result |
|---|---|---|
| Water : Powder Ratio | – | 0.14 – 0.15 |
| Fresh Wet Density | ASTM C138 | 2.20 ± 0.05 g/cc |
| Compressive Strength | ASTM C109 |
>20 MPa @ 1 Day ≥45 MPa @ 28 Days |
| Flexural Strength | ASTM C348 | ≥ 7 N/mm² @ 28 Days |
| Drying Shrinkage | ASTM C157 | < 800 microstrain @ 28 Days |
| Adhesion Bond Strength | EN 1015-12 | > 2.0 N/mm² |
| Maximum Aggregate Size | – | 1 mm |
| Pot Life | @ 27°C | ~ 30 minutes |
| Application Thickness | – | 10 mm – 200 mm (in layers) |
| Standard Pack Size | – | 25 KG |
| Packaging | – | Bags |
