RepoStruct 40
RepoStruct 40
High-Performance, Polymer-Modified, Fibre-Reinforced Repair Mortar
A polymer-modified fibre-reinforced repair mortar designed for structural repair of damaged concrete. It offers excellent adhesion, improved tensile strength and crack resistance, making it suitable for patch repairs, surface restoration and structural rehabilitation.
Features and Benefits
- High compressive strength with early strength gain
- Low rebound and excellent pumpability
- Shrinkage controlled for crack-free repairs
- Excellent bond to concrete and reinforcement
- Chloride-free and non-corrosive
- Compatible with HAHNE protective coatings and waterproofing systems
Area of Applications
- Restoration of damaged or spalled structural concrete
- Jacketing and rebuilding of columns, beams, and walls
- Repair of fire-damaged and chloride-affected concrete
- Large-area reinstatement of industrial and marine structures
- Micro-concrete infill behind shuttering where vibration is difficult
Technical Specifications
| Property | Test Method | Result |
|---|---|---|
| Water : Powder Ratio | – | 0.14 – 0.15 |
| Fresh Wet Density | ASTM C138 | 2.20 ± 0.05 g/cc |
| Compressive Strength | ASTM C109 |
>20 MPa @ 1 Day ≥45 MPa @ 28 Days |
| Flexural Strength | ASTM C348 | ≥ 7 N/mm² @ 28 Days |
| Drying Shrinkage | ASTM C157 | < 800 microstrain @ 28 Days |
| Adhesion Bond Strength | EN 1015-12 | > 2.0 N/mm² |
| Maximum Aggregate Size | – | 1 mm |
| Pot Life | @ 27°C | ~ 30 minutes |
| Application Thickness | – | 10 mm – 200 mm (in layers) |
| Standard Pack Size | – | 25 KG |
| Packaging | – | Bags |
